Characteristics Standard values | Standard values |
Total power Main motor+servo+hydraulic and vacuum | 32.5kw 28.45kw |
Total weight | 7000Kg |
Main motor power | 18.5kw |
Y axis travel X axis travel Z axis travel A axis travel C axis travel | 2420mm 3600mm 380mm 0-90° -5-365° |
Y axis power X axis power Z axis power A axis power C axis power | 1.3kw 1.5kw 1.0kw 0.85kw 1.0kw |
Hydraulic motor power | 2.25kw |
Vacuum pump motor power | 0.75kw |
Control mode | DDX+PLC |
Saw blade diameter range | 350-625mm |
Saw blade center hole diameter | 50mm |
Flange diameter | 200mm |
Air consumption | 20L/min |
Water consumption | 35L/min |
Working platform size | L 3600mm*W2050mm |
Machine size | L 6058.3mm*W 3295mm*H 3708.66mm |
